Silicon Compiler Dashboard
This dashboard show some of the designs automatically compiled by SiliconCompiler. To add your own design to the gallery, please submit a PR to github.com/siliconcompiler/scgallery
| total-area fmax | asap7 | freepdk45 | ihp130 | skywater130 | gf180 |
|---|---|---|---|---|---|
| aes |  3,261 μm² 796.5 MHz |  39,081 μm² 847.9 MHz |  332,326 μm² 94.9 MHz |  254,388 μm² 46.6 MHz |  1.14 mm² 58.5 MHz |
| ariane |  123,998 μm² 159.4 MHz |  1.55 mm² 148.5 MHz | | | |
| black_parrot |  163,217 μm² 216.6 MHz |  1.96 mm² 137.7 MHz | | | |
| caliptra-datavault |  19,568 μm² 604.6 MHz |  239,419 μm² 581.8 MHz | | | |
| caliptra-sha512 |  15,641 μm² 279.8 MHz |  207,134 μm² 266.7 MHz |  1.83 mm² 37.5 MHz |  976,045 μm² 15.7 MHz |  4.80 mm² 17.9 MHz |
| dynamic_node |  4,171 μm² 924.4 MHz |  53,590 μm² 631.9 MHz |  502,153 μm² 69.9 MHz |  243,452 μm² 40.8 MHz |  1.14 mm² 34.4 MHz |
| ethmac |  5,058 μm² 1,571.9 MHz |  65,910 μm² 1,318.2 MHz |  657,749 μm² 231.4 MHz |  1.30 mm² 62.7 MHz |  2.63 mm² 69.8 MHz |
| fazyrv |  636 μm² 951.4 MHz |  8,103 μm² 554.5 MHz |  169,207 μm² 107.5 MHz |  1.07 mm² 28.7 MHz |  1.13 mm² 34.4 MHz |
| gcd |  123 μm² 1,648.3 MHz |  1,788 μm² 2,125.8 MHz |  14,174 μm² 150.0 MHz |  7,767 μm² 78.7 MHz |  41,659 μm² 73.1 MHz |
| heartbeat |  13 μm² 4,324.6 MHz |  163 μm² 3,364.9 MHz |  1,306 μm² 553.0 MHz |  776 μm² 207.0 MHz |  3,353 μm² 219.8 MHz |
| ibex |  3,218 μm² 300.7 MHz |  40,282 μm² 341.4 MHz |  367,525 μm² 28.9 MHz | |  1.01 mm² 18.9 MHz |
| jpeg |  13,498 μm² 488.9 MHz |  195,147 μm² 555.9 MHz |  1.71 mm² 62.0 MHz |  965,247 μm² 31.6 MHz |  4.58 mm² 37.7 MHz |
| mock_alu |  3,474 μm² 422.0 MHz |  45,365 μm² 430.3 MHz |  449,608 μm² 66.8 MHz |  220,156 μm² 24.6 MHz |  1.05 mm² 24.3 MHz |
| picorv32 |  3,342 μm² 575.4 MHz |  43,677 μm² 570.2 MHz |  397,571 μm² 72.1 MHz |  202,732 μm² 34.1 MHz |  969,748 μm² 46.5 MHz |
| riscv32i |  2,536 μm² 330.5 MHz |  31,237 μm² 402.5 MHz |  290,108 μm² 31.9 MHz |  145,565 μm² 21.7 MHz |  703,715 μm² 20.0 MHz |
| serv |  303 μm² 1,479.6 MHz |  3,706 μm² 978.2 MHz |  38,032 μm² 211.2 MHz |  19,399 μm² 63.3 MHz |  90,421 μm² 72.0 MHz |
| spi |  44 μm² 3,904.2 MHz |  463 μm² 2,747.5 MHz |  4,442 μm² 470.9 MHz |  2,042 μm² 164.8 MHz |  9,599 μm² 200.0 MHz |
| swerv |  37,404 μm² 238.6 MHz |  456,307 μm² 256.8 MHz | | |  11.11 mm² 15.2 MHz |
| tiny_rocket |  8,889 μm² 472.3 MHz |  115,033 μm² 478.2 MHz | |  2.62 mm² 28.0 MHz |  4.53 mm² 30.9 MHz |
| uart |  157 μm² 1,903.0 MHz |  2,077 μm² 1,656.5 MHz |  18,877 μm² 216.7 MHz |  10,462 μm² 54.3 MHz |  52,327 μm² 89.9 MHz |
| zerosoc | | | |  2.46 mm² 17.4 MHz | |
